Engine:
Air Cooled 4-Stroke Gas Powered, Electronic Fuel Injected (EFI)
Transmission:
Fully Automatic w/ Reverse
Start Type:
Electric Key Start
Tire/Rim Size:
Front 23x7-10 / Rear 22x10-10 (Chrome Wheels)
Features:
Full Size ATV, Adjustable Speed Limiter for Control, Large Digital Display, Seat with Back Rest, LED high and low beam lights, LED daytime running lights and turning lights, LED drive light, brake light, turning light, License plate light, Front/Rear Rack Included.
| Specification : | | Engine: | 224.2CC, CVT, F+N+R, Four-stroke, single cylinder, SOHC | | Battery | 12V12AH | | Drive: | Chain drive, rear drive | | Cooling: | Oil cooling | | Ignition: | Electric start | | Max Power: | 10.8kW/7500rpm | | Max Torque: | 15.5Nm/6100rpm | | Max Speed: | 70km/h | | Tank capacity: | Steel, 14L, with oil measurement sensor | | Speed meter: | HD LCD screen | | F & R Tyre : | "W" pattern , Front tyre 23×7-10, Aluminium alloy
"W" pattern, Rear tyre 22×10-10, Aluminium alloy | | Brake: | F hydraulic disc brake by hand, R hydraulic disc brake by foot | | Suspension | Front: Double wishbone independent suspension
Rear : Flat fork non-independent suspension | | USB port: | With | | Rear & Front Rack: | With | | Rear backrest | With | | Muffler: | Steel | | Horn: | With | | Handlebar protector: | With | | Head light: | LED high and low beam lights, LED daytime running lights and turning lights | | Rear light: | LED drive light, brake light, turning light, License plate light | | Dimension : | | Product Built Size: | 2050×1100×1225mm | | Number of riders: | 2 persons | | Wheel Base | 1200mm | | Ground Clearance : | 170mm | | Seat Height: | 840mm | | Footrest Height: | 310mm | | Max Load: | 150kg | | N.W.: | 205kg | | Product Packing Size: | 1800×1150×860mm |
US EPA (Environmental Protection Agency) APPROVED
NOT CA LEGAL Important Safety Information
Recommended for riders 16 years of age and older. The Manufacture of this product recommends that all ATV riders take a training course and thoroughly read their owner's manual. An adult must supervise riders younger than 16 years of age.Customers, please check the Manufactures ATV & Scooter Safety & ATV Safety Alert for more information.
A professional mechanic or reputable shop must perform the assembly on the vehicle and complete the manufactures prep list.
Read Owner’s Manual and all on-product warnings. ATVs can be hazardous to operate. For your safety, Always wear a helmet, eye protection, and protective gear. Never carry a passenger. Never ride under the influence of drugs or alcohol. Never ride on public roads or pavement. Be extra careful on difficult terrain. All children under the age of 16 riding ATVs should always have adult supervision at all times.
|
|
|
 |
|
 |
|
