Engine / Drive Train Specifications
Engine: 124cc, 4-stroke
Cylinder Arrangement: Single cylinder
Max Horsepower: 6.57HP/8000RPM
Max Torque: 5.17ft-lb/5000RPM
Bore × Stroke: 52mm x 55.5mm
Compression Ratio: 9.0:1
Cooling System: Air cooled
Transmission: Fully automatic with reverse
Start System: Electric start
Ignition: CDI
Final Drive: Chain drive
Max Limited Speed: 15MPH(Y-10+ ATV)
Battery: 12V5Ah
Frame / Body / Suspension / Brakes
Front Suspension: Dual A-Arm with dual shock absorbers.
Rear Suspension: Swing arm with central single shock absorber.
Front Brake: Drum brake.
Rear Brake: Hydraulic disc brake.
Front Tires: 19x7-8
Rear Tires: 18x9.5-8
Capacities / Dimensions
Max Load: 187lbs
Gross Weight: 233.73lbs
Net Weight: 229.32lbs
Overall Length: 59.85inches
Overall Width: 37.0inches
Overall Height: 36.22inches
Carton Dimensions (L × W × H): 53.55x29.93x24.02inches
Seat Height: 27.56inches
Wheelbase: 39.37inches
Ground Clearance: 3.94inches
Gas Tank Capacity: 0.58gal
Fuel Consumption: 89.78mpg
Off-Road Legal:
US EPA (Environmental Protection Agency) APPROVED
Not For Sale In California (This unit is not California Air Resources Board Compliant & can not be registered for use)For California customers please check our California Legal Section for CA DMV registerable vehicles.
Important Safety Information
Recommended for riders 10 years of age and older. The Manufacture of this product recommends that all ATV riders take a training course and thoroughly read their owner's manual. An adult must supervise riders younger than 16 years of age.
Customers, please check the Manufactures ATV & Scooter Safety & ATV Safety Alert for more information.
A professional mechanic or reputable shop must perform the assembly on the vehicle and complete the manufactures prep list.
Read Owner’s Manual and all on-product warnings. ATVs can be hazardous to operate. For your safety, Always wear a helmet, eye protection, and protective gear. Never carry a passenger. Never ride under the influence of drugs or alcohol. Never ride on public roads or pavement. Be extra careful on difficult terrain. All children under the age of 16 riding ATVs should always have adult supervision at all times.
