Engine / Drive Train Specifications

Engine: 223cc, 4-stroke, Balance shaft

Cylinder Arrangement: Single cylinder

Max Horsepower: 16.09HP/7500RPM

Max Torque: 13.28ft-lb/5000RPM

Bore × Stroke: 2.58x2.61inches

Compression Ratio: 9.0:1

Cooling System: Air cooled

Transmission: 5-Speed, Manual

Start System: Electric and Kick Start

Ignition: DELPHI Electronic Fuel Injection

Final Drive: Chain drive

Max Speed: 78MPH

Battery: 12V6.5Ah

Frame / Body / Suspension / Brakes

Front Suspension: Dual inverted hydraulic forks and shock absorbers.

Rear Suspension: Swing arm with central shock absorber.

Front Brake: Hydraulic disc brake.

Rear Brake: Hydraulic disc brake

Front Tires: 80/100-21

Rear Tires: 110/100-18

Capacities / Dimensions

Max Load: 331lbs

Gross Weight: 328.55lbs

Net Weight: 293.27lbs

Overall Length: 82.3inches

Overall Width: 36.2inches

Overall Height: 56.7inches

Carton Dimensions (L × W × H): 69.69x18.11x33.86inches

Seat Height: 35.4inches

Wheelbase: 53.93inches

Ground Clearance: 8.3inches

Gas Tank Capacity: 3.7gal

Fuel Consumption: 65.34mpg

Available colors: Black, Red, Blue, Green.
